I'm working on developing a python application for Ubuntu that enables a user to have their desired resolution without requiring graphics drivers.
In order to do this I've been using xrandr.
However I've now encountered a problem, despite searching for others with similar problems and attempting the fixes.
Here is my code (I'm new to Python, this being my first application, so the code will probably be very messy and inefficient to others - I also need to relocate some of the code, but hopefully it's readable):
#!/usr/bin/python
import gtk, sys
import os, commands # enables us to use xrandr
class ResolutionX(gtk.Window):
# create an instance of ResolutionX
def __init__(self):
# constructor
super(ResolutionX, self).__init__()
# set the default window values
self.set_title("ResolutionX")
self.set_size_request(600, 200)
self.set_position(gtk.WIN_POS_CENTER)
fix = gtk.Fixed()
# resolution combo box
ResComboB = gtk.combo_box_new_text()
ResComboB.append_text('1024 x 768')
ResComboB.append_text('1280 x 960')
ResComboB.append_text('1366 x 768')
ResComboB.append_text('1280 x 1024')
ResComboB.append_text('1440 x 900')
ResComboB.append_text('1440 x 960')
ResComboB.append_text('1440 x 1080')
ResComboB.append_text('1600 x 1200')
ResComboB.append_text('1920 x 1080')
ResComboB.append_text('1920 x 1200')
ResComboB.set_active(0)
ResComboB.connect("changed", ResComboB_changed)
label = gtk.Label("Resolution:")
# apply button
applyBtn = gtk.Button("Apply")
applyBtn.set_size_request(110, 29)
applyBtn.connect("clicked", applyBtn_on_clicked)
# add widgets to the main window
fix.put(ResComboB, 98, 78)
fix.put(label, 30, 85)
fix.put(applyBtn, 470, 78)
self.add(fix)
self.connect("destroy", gtk.main_quit)
self.show_all()
def ResComboB_changed(ResComboB):
string = ResComboB.get_active_text()
stringRes = string.replace("x", "")
echo = "echo "
stringConfig = os.popen("cvt " + stringRes).readlines()
# TODO: create a hidden directory in /home folder
# create the file [config.sh]
fWrite = open('config.sh', 'w')
# write the xrandr configuration into the file so we can edit it
print >> fWrite, stringConfig
fWrite.close()
fRead = open('config.sh', 'r')
# TODO: remove last 4 characters from readString // DONE
# get input from [config.sh] and edit according to the choice of resolution
if (string=="1024 x 768"):
for line in fRead:
storedString = line
readString = storedString[83:]
readString = readString[:76]
print readString # verification
resolution = readString[:16]
if (string=="1366 x 768"):
for line in fRead:
storedString = line
readString = storedString[76:]
readString = readString[:76]
print readString # verification
resolution = readString[:16]
if (string=="1280 x 960") or (string=="1440 x 900"):
for line in fRead:
storedString = line
readString = storedString[84:]
readString = readString[:77]
print readString # verification
resolution = readString[:16]
if (string=="1440 x 960"):
for line in fRead:
storedString = line
readString = storedString[77:]
readString = readString[:76]
print readString # verification
resolution = readString[:16]
if (string=="1280 x 1024") or (string=="1440 x 1080") or (string=="1600 x 1200") or (string=="1920 x 1080") or (string=="1920 x 1200"):
for line in fRead:
storedString = line
readString = storedString[85:]
readString = readString[:81]
print readString # verification
resolution = readString[:17]
os.system("xrandr --newmode " + readString)
fRead.close()
def applyBtn_on_clicked(applyBtn):
# detect and store monitor output type - eg. VGA1, DVI-0
monitorType = os.popen("xrandr | grep ' connected ' | awk '{ print$1 }'").readlines()
fWrite = open('config.sh', 'w')
print >> fWrite, monitorType
fWrite.close()
# get the input from [config.sh]
fRead = open('config.sh', 'r')
for line in fRead:
CmonitorType = line
fRead.close()
# edit CmonitorType so we can use it
CmonitorType = CmonitorType[2:]
CmonitorType = CmonitorType[:7]
print CmonitorType # verification
os.system("xrandr --addmode " + CmonitorType + resolution)
ResolutionX()
gtk.main()
I get this error:
Traceback (most recent call last):
File "file.py", line 129, in applyBtn_on_clicked
os.system("xrandr --addmode " + CmonitorType + resolution)
NameError: global name 'resolution' is not defined
How can I solve this problem?
1 Answer
Make the following changes to your script:
Below line def ResComboB_changed(ResComboB): add the following to it, so it looks like this:
def ResComboB_changed(ResComboB):
global resolution
or add resolution = "" above the def line like this:
resolution = ""
def ResComboB_changed(ResComboB):
Hope that helps ;)
