I've provided a small reproducible example below. I would like to generate tabs in quarto for each of the ggplot objects within a named list plots. The below quarto document would render the figures in their own 2nd level heading, but not in tabs as expected.
---
title: "Untitled"
format: html
---
{r}
library(tidyverse)
data <- iris %>% as_tibble()
plots <- data %>%
group_nest(Species) %>%
deframe() %>%
map(., ~ {
ggplot(.x, aes(x = Sepal.Length, y = Sepal.Width)) +
geom_point()
})
# Iris Plots
::: {.panel-tabset}
{r}
#| column: screen
#| fig-width: 12
#| fig-height: 8
#| fig-align: center
#| results: asis
iwalk(plots, ~ {
cat('## ', .y, '\n\n')
print(.x)
cat('\n\n')
})
:::
The document would correctly render the plots within tabs as expected when the chunk-options (all except results:asis) were removed.
# Iris Plots
::: {.panel-tabset}
{r}
#| results: asis
iwalk(plots, ~ {
cat('## ', .y, '\n\n')
print(.x)
cat('\n\n')
})
:::
1 Answer
Updated Answer
Now if you want to generate tabsets which would expand the whole width of the screen, wrap the .panel-tabset div with the .column-screen div.
Note that, we have to use more : for .column-screen than that of .panel-tabset div. We have used three : for .panel-tabset, so we have to use four more of the : to create div for column-screen.
---
title: "Panel tabs"
format: html
---
{r}
library(tidyverse)
data <- iris %>% as_tibble()
plots <- data %>%
group_nest(Species) %>%
deframe() %>%
map(., ~ {
ggplot(.x, aes(x = Sepal.Length, y = Sepal.Width)) +
geom_point() +
theme_bw(
base_size = 18 # to increase the size of the plot elements
)
})
# Iris Plots
:::: {.column-screen}
::: {.panel-tabset}
{r}
#| results: asis
#| fig-width: 14
#| fig-height: 6
iwalk(plots, ~ {
cat('## ', .y, '\n\n')
print(.x)
cat('\n\n')
})
:::
::::
Now the panel tabsets are expanded to the width of the screen.
Also Note that, I have increased the size of elements of the plot (e.g. axis.title, axis.text etc.) with base_size = 18 in plot-theme.
