I am unsure if this is the correct place for this question. I am attempting to obtain the axis position values from a joystick /dev/input/js0 on my system. If I run jstest /dev/input/js0 it will give me live feedback on all buttons and axis positions.
I am trying to feed this information into my C program to control servos. Is there a function for doing this? I have not worked much with input devices in programming so this is all new to me.
3 Answers
You can run this python code to read events.
You can also use a high level module python-evdev.
#!/usr/bin/env python
import struct
infile_path = "/dev/input/js0"
EVENT_SIZE = struct.calcsize("llHHI")
file = open(infile_path, "rb")
event = file.read(EVENT_SIZE)
while event:
print(struct.unpack("llHHI", event))
(tv_sec, tv_usec, type, code, value) = struct.unpack("llHHI", event)
event = file.read(EVENT_SIZE)
Sample output:
(73324490, 8454144, 55242, 1118, 25231360)
(73324490, 42008576, 55242, 1118, 58785792)
(73324490, 75563008, 55242, 1118, 92340224)
(73324490, 109117440, 55242, 1118, 125894656)
(73324490, 142671872, 55242, 1118, 159449088)
(73324490, 176226304, 55242, 1118, 193003520)
(73324490, 209780736, 55242, 1118, 226557952)
(73324490, 243335168, 55242, 1118, 8519680)
(73324490, 25296896, 55242, 1118, 42074112)
(73324490, 58884097, 55242, 1118, 75661313)
(73324490, 92405760, 55242, 1118, 109215745)
(73324490, 125992961, 55242, 1118, 142737408)
(73324490, 159514624, 55242, 1118, 176324609)
(73327790, 84041474, 58542, 1118, 84049919)
(73328030, 84044852, 58782, 1118, 84017152)
(73331790, 33749013, 62542, 1118, 33742256)
(73331790, 33736851, 62562, 1118, 33731108)
(73331830, 33723339, 62602, 1118, 33718273)
(73332090, 33723339, 62862, 1118, 33685504)
Building on the post from kev
From the linux/joystick.h file:
struct js_event {
__u32 time; /* event timestamp in milliseconds */
__s16 value; /* value */
__u8 type; /* event type */
__u8 number; /* axis/button number */
};
So the python format should be:"LhBB"
infile_path = "/dev/input/js0"
EVENT_SIZE = struct.calcsize("LhBB")
file = open(infile_path, "rb")
event = file.read(EVENT_SIZE)
while event:
print(struct.unpack("LhBB", event))
(tv_msec, value, type, number) = struct.unpack("LhBB", event)
event = file.read(EVENT_SIZE)
sample output from XBOX One S controller:
// type=button, number=button number
//msec, value, type, number
(2114530, 1, 1, 0) // A pressed
(2114670, 0, 1, 0) // A released
(2116490, 1, 1, 1) // B pressed
(2116620, 0, 1, 1) // B released
(2117370, 1, 1, 2) // X pressed
(2117520, 0, 1, 2) // X released
(2118220, 1, 1, 3) // Y pressed
(2118360, 0, 1, 3) // Y released
This page: has a nice writeup on how to read the info from /dev/input/js0
The format of the events you read from the file are documented here: . It's a simple struct containing a timestamp, the event type and identifier and the value:
struct input_event {
struct timeval time;
unsigned short type;
unsigned short code;
unsigned int value;
};
