Getattributes Function - Documentation for Bmc Helix Cmdb 22.1

Getattributes Function - Documentation for Bmc Helix Cmdb 22.1

Retrieves multiple attributes for the specified class.

WSDL operation

<operation name="GetAttributes" parameterOrder="inargs">
<input message="tns:GetAttributesRequest"
	 name="GetAttributesRequest"/>
<output message="tns:GetAttributesResponse"
	 name="GetAttributesResponse"/>
<fault message="tns:AtriumFault" name="AtriumFault"/>
</operation>

WSDL messages

<message name="GetAttributesRequest">
	<part element="types:GetAttributes" name="inargs"/>
</message>
<message name="GetAttributesResponse">
	<part element="types:GetAttributesOutput" name="outargs"/>
</message>
<message name="AtriumFault">
	<part element="common:AtriumFault" name="errargs"/>
</message>

XSD schema

<element name="GetAttributes">
	<complexType>
		<sequence>
			<element name="lang" type="string"/>
			<element name="classNameId" type="common:ClassNameId"/>
			<element name="attributeNames"
				type="common:ArrayOf_String" nillable="true" />
			<element name="extensions" type="common:ExtensionsList"
				nillable="true" />
		</sequence>
	</complexType>
</element>
<element name="GetAttributesOutput">
		<complexType>
	<sequence>
			<element name="attributeInfoList"
				type="common:AttributeInfoList"/>
			<element name="status" type="common:StatusList"/>
			<element name="extensions" type="common:ExtensionsList"
				nillable="true" />
		</sequence>
	</complexType>
</element>
<element name="AtriumFault">
	<complexType>
		<choice>
			<element name="serviceFault"
				type="tns:AtriumServiceFault" />
			<element name="backendFault"
				type="tns:AtriumBackendFault" />
		</choice>
	</complexType>
</element>

Input arguments

lang

The language of the product specific to the locale. If no language is specified, the default language is used.

classNameId

The name of the class. It is a two-part structure that contains the namespace name and the class name. See ClassNameId.

attributeNames

The names of the attributes to retrieve.



Return values

attributeInfoList

Retrieves attribute information. See AttributeInfoList.

status

A list of zero or more notes, warnings, or errors generated from a call of this operation.

extensions

A list of extension types for the operation.

Fault message
