Warning
The CRA server installed and configured was tested for integrity and performance with the BMC application code. Deploying other applications on the server might have unexpected results.
Use the following information to complete the Common RESTful API for TOMCAT options panel during the configuration process.
Important
The following panel information pertains to the earlier (prior to 4.00.00 release) version of the Installation System.
Common RESTful API for TOMCAT options panel
Common RESTful API for TOMCAT options
Command ===> ________________________________________________ Scroll ===> CSR
Enter the UNIX File System values and product options.
Runtime UNIX file system options
Numeric UNIX User-ID . . . . . . . .
Numeric UNIX Group-ID . . . . . . . .
Root directory for Common RESTful API for TOMCAT file path
Common RESTful API for TOMCAT properties
TOMCAT host name . . . . . . . . . . localhost
TOMCAT port number (HTTP) . . . . . . 15565
TOMCAT SSL port number (SSL/TLS) . . 18443
TOMCAT AJP port number (SSL/TLS) . . 18010
| Field | Description |
|---|---|
Numeric UNIX User-ID | A numeric UNIX user ID (USS UID) for the file system. If you are unsure of the USS UID, consult your security administrator. Important The USS UID requires update access to the root directory. |
Numeric UNIX Group-ID | A numeric UNIX group ID (USS GID) for the file system. If you are unsure of the USS GID, consult your security administrator. |
Root directory for Common RESTful API for TOMCAT file path | The location of the Tomcat and Java directories for the CRA . Additional directory levels might be appended to the path provided. Important
|
TOMCAT host name | The host name by which you will access CRA . By default, this is the LPAR name where you complete the configuration. You can specify a different host name instead. |
TOMCAT port number (HTTP) | The default port number for the Tomcat server used by CRA when you are using the HTTP protocol. Specify the port number that you have reserved for CRA . This value determines the URL for launching CRA . The URL will be:
|
TOMCAT SSL port number (SSL/TLS) | The default port number for the Tomcat server used by CRA when you are using the HTTPS protocol. Specify the port number that you have reserved for CRA . This value determines the URL for launching CRA . The URL will be:
|
TOMCAT AJP port number (SSL/TLS) | The default port number for the Tomcat server used by CRA when you are using the AJP protocol. Specify the port number that you have reserved for CRA . This value determines the URL for launching CRA . The URL will be: |
