JIC Steps In
The SAE went on to adopt this JIC standard as well. It’s important to note that the AN and JIC specifications are no longer in existence in most cases. The majority of the hydraulic population agrees, the JIC (or SAE) 37 degree fittings are generally interchangeable with AN fittings.
Is 6AN the same as 3 8?
3AN hose has the same ID as a 3/16″ tube. This means that 6AN hose will not introduce any appreciable flow restriction in a fuel system designed around 3/8″ OD rigid tubing. Note that this does not match AN Bolt Nomenclature. AN bolt sizes translate directly to bolt OD in sixteenths of an inch.
What is 6 an fitting?
In bolts the number refers to the diameter of the bolt whereas in a fitting it refers to the OD of the tube and thereby have different threads. For example, AN6 bolt has a 3⁄8-24 thread whereas an -6 AN fitting has a 9⁄16-18 thread.
How do you determine thread size?
Measure from the bottom of the head to the end of the threaded area in millimeters. For instance, it might be 8 millimeters. Then, measure the diameter (width) of the threaded area in millimeters. This might be 4 millimeters across.
What does thread size mean?
Thread sizes in inches are specified by diameter and threads per inch. For example, in the screw size 10-24, the first digit refers to the thread diameter, the and second digit is threads-per-inch (TPI). When the diameter smaller than 1/4”, the value is indicated by a number, like #1 or No. 1.
ARE AN fittings the same as JIC?
JIC fittings are dimensionally identical to AN (Army-Navy) fittings, but are produced to less exacting tolerances and are generally less costly.
How is BSP measured?
How to Measure Your BSP Fittings
Measure the outer diameter (OD) of the thread (in inches)Then subtract 25% from this (¼ inch)Therefore, if the OD of a BSP thread measures 1”, the thread size will be ¾ .
What an fitting is 3 8?
Hose diameters are assigned AN numbers. Using your automotive hose size, choose from the chart below to find the AN equivalent for hose, hose ends and adapter fittings. For example: a 3/8″ standard hose equals -6 AN.
Why is it called JIC fitting?
What does JIC stand for? JIC stands for the Joint Industries Council, which first standardized industrial use fittings. These compression couplings have a 37° flared seat on the male and female threaded connections.
What is an 8 thread?
“AN” Thread Sizes
For example, an -8 AN fitting translates to an 8/16 inches, or 1/2-inch.
