Most consumer saws use a type of 3/8″ chain called “low profile”. We call it Picco. A few older saws use 1/2″ pitch chain. The second is the gauge, or the thickness of the drive lugs. 0.050″ (1.3 mm) and 0.058″ (1.5 mm) are most common, 0.043″ (1.1 mm) and 0.063″ (1.6mm) less common.
Does gauge matter on chainsaw chain?
The gauge measurement of a saw chain tells a pro user about the strength of a chain’s drive links. Thicker drive links are usually stronger, but they are heavier. Weight affects performance, and to maximize cutting speed, weight should be kept to a minimum.
How do I know what size chain I need for my chainsaw?
To get the correct size, simply count 3 rivets on the chain and measure the distance between them from the centre points. Now divide this by half to get your size. As an example, three rivets that measure ½ an inch across divided by two gives you a pitch of a ¼ inch.
What is the difference between a 3/8 and a .325 chainsaw chain?
The . 325 may be smaller and faster, but it may not be your best bet for your everyday needs. The three-eighths-inch chain is durable and lasts longer than its smaller cousin. This makes it one of the more popular switches for chainsaw users who want to get more out of their saw.
What pitch is a .325 chainsaw chain?
050″ Gauge Saw Chain, 18″
What does 3 mean on a Stihl chain?
Find the gauge of the chain by locating the number stamped on the drive link. A 1 equals a 0.043-inch gauge, 3 equals a 0.050-inch gauge, 5 corresponds to a 0.058-inch gauge, 6 means the chain has a 0.063-inch gauge. A 0 means the chain has a 0.080-inch gauge, but this gauge size is found only on the Harvester chain.
What does S56 mean on chainsaw chain?
Showing 1-2 of 2 answers. The difference is the width of the chain track. S56 is . 050″ and R56 is . 043″.
What chainsaw pitch is best?
Experts say the best chainsaw chain for cutting firewood is the Husqvarna High Performance 18 inches, 0.05 gauge, 0.325 pitch chain.
Which chainsaw chain is best?
BEST OVERALL: Husqvarna Chainsaw Chain 16″ .050 Gauge.RUNNER UP: Oregon R40 AdvanceCut 10-Inch Chainsaw Chain.BEST BANG FOR THE BUCK: Oregon S33 AdvanceCut 8-Inch Chainsaw Chain.BEST FULL CHISEL: Forester Chainsaw Chain Loop, 24″ Full Chisel.BEST SEMI CHISEL: Oregon S39 AdvanceCut 10-Inch Semi-Chisel Chain.
How is chain measured?
To measure the chain size, if you have just the sprocket, use calipers to measure between the teeth. Measure from center to center of where the chain roller would set between the teeth that will give you the pitch. Once you know the pitch you can determine what chain size you would need.
Are chainsaw chains universal?
No, chainsaw blades are not universal, not every bar and chain will fit on your machine. Chainsaw chains need to have the correct specification to fit on your bar. If you have a chain that is too long or too narrow it will not fit. Mixing brands of chains is no problem as long as they are compatible.
What are the different types of chainsaw chains?
Chainsaw chains come in three main varieties. They come in full chisel, semi chisel and low profile chains, with each being used for different tasks. The chisel refers to how the teeth are cast on the chain itself – which then determines how the chain cuts through the wood.
What size file do you use on a 3/8 chainsaw chain?
The packaging of your chainsaw blade will tell you if it is 7/32 or 5/32 etc. The pitch of the chain is usually inscribed on it and it will indicate a ¼ inch or 3/8. These pitches will need a 5/32 file.
What size bar can you put on a ms261?
20″ is the longest bar available for the . 325 chain on the 261 and is the realistic limit.
How do you tell the pitch of a chainsaw chain?
To determine the pitch (chain size), you’ll need to measure the distance between any three consecutive rivets, then divide the result by 2. The rivets are the small, round pegs/studs that hold the chain segments together. Measure from the first to the third, then divide that number in half to get your chain pitch.
