Subsequently, one may also ask, how is bolt torque value calculated?
- T = Target tightening torque in foot-pounds. [For metric in N-m, use metric units for D and P and divide by 1000]
- k = Coefficient of friction (nut factor), varies by type of lubricant.
- D = Bolt's nominal diameter (inches, mm)
- P = Bolt's desired load (lb, N)
Beside above, at what torque will a bolt break? A perfect 1/2-13 Grade 5 waxed bolt will break if it is tightened to 81 foot pounds because the K factor is drastically lower. The bolts are fine, but the application changed.
Correspondingly, how do you determine torque value?
The marking check: After tightening the bolt, mark the bolt surface and that of the product or workpiece. Then loosen the bolt. Re-tighten it until the markings re-align. The torque needed to return the bolt to its original position is the torque value of the bolt.
What is the torque spec?
Generally, the higher the rotational resistance, the greater tension in the threaded fastener. In other words, the more effort it takes to tighten a bolt, the tighter it is. Torque is measured as a unit of force acting on a rotating lever of some set length.
What is the torque for a 3/4 bolt?
| GRADE 5 | ||
|---|---|---|
| Coarse Thread | ||
| 1/4-20 (.250) | 2025 | 76 in lbs. |
| 5/16-18 (.3125) | 3338 | 13 ft lbs. |
| 3/8-16 (.375) | 4950 | 23 ft lbs. |
What does torque mean?
