Similarly, what does a section drawing show?
A 'section drawing', 'section' or 'sectional drawing' shows a view of a structure as though it had been sliced in half or cut along another imaginary plane. Plan drawings are in fact a type of section, but they cut through the building on a horizontal rather than vertical plane.
Also Know, what is Plan and section? A section plan is a vertical slice drawings showing the internal features of your property. It is similar to an elevation plan, however, it shows the internal features of the property. The section plan is usually combined with other plans on a measured building survey. This can include floor plans, elevations, etc…
Keeping this in consideration, what are the types of sectioning?
There are a number of different types of sectional views that can be drawn. A few of the more common ones are: full sections, half sections, broken sections, rotated or revolved sections, removed sections, offset sections, and assembly sections.
What is a full section view?
Full Sections When a cutting plane line passes entirely through an object, the resulting section is called a full section Fig.
How do I create a section view?
- Click Layout tab Create View panel Section drop-down Full.
- Click the view you want to use as the parent view.
- Click in the drawing area to indicate the start point of the section line.
What is a removed section view?
