Shadowgraph is an optical method that reveals non-uniformities in transparent media like air, water, or glass. It is related to, but simpler than, the schlieren and schlieren photography methods that perform a similar function. Shadowgraph is a type of flow visualisation.

What is the definition of Shadowgraphs?

1 : shadow play. 2 : a photographic image resembling a shadow.

What does a shadowgraph do?

The shadowgraph is the simplest form of optical system suitable for observing a flow exhibiting variations of the fluid density. In principle, the system does not need any optical component except a light source and a recording plane onto which to project the shadow of the varying density field (Figure 1).
